Name: Microgrid For Small Workshop Applications With LFP Storage 8kW 14kWh System
Brand: Jiangsu Zhitai New Energy Technology Co., Ltd
SKU: ZT-ESSPLUS-8-51280
Price: Negotiable USD
Availability: InStock

Microgrid For Small Workshop Applications With LFP Storage 8kW 14kWh System

14kWh Microgrid

8kW Microgrid

LFP Storage Microgrid

Place of Origin:

China

Brand Name:

ZT-TEK

Certification:

IEC 62619-2022, UN 38.3

Model Number:

ZT-ESSPLUS-8-51280

Request A Quote

ZT-TEK Microgrid for small workshop Applications with LFP Storage 8kW 14kWh system

ZT-ESSPLUS-8-51280

8kW PCS with AC 400/230V output

14.336kWh lithium-ion battery energy storage system (can be expanded)

In industrial microgrids, LFP batteries are integral to ensuring a reliable and efficient power supply. They allow for load leveling, where excess solar energy is stored during off-peak hours and used during high-demand periods. This reduces the strain on the main grid and minimizes operational costs associated with backup generators. The high safety profile of LFP batteries also ensures that industrial facilities can operate with minimal risk, even in high-demand environments where power reliability is critical for continuous operations.

Example Use Cases:
Remote Communities: Microgrids with solar, batteries, and generators are ideal for remote communities that are off the main grid, reducing reliance on expensive fuel deliveries for generators and improving sustainability.
Industrial Sites and Military Bases: In places where continuous power is essential and grid reliability is low, microgrids can ensure uninterrupted operation.
Urban Applications: Microgrids can be deployed in urban areas to improve resilience against blackouts and enable integration of renewable energy sources into the grid.

Data sheet

OFF-Grid	Model	ZT-ESSPLUS-8-51280
System parameter	Output Voltage	AC, 3Phases,400/230V
	Output frequency	50Hz/60Hz
	Rated output power	8kW
	Max output power	9.6kW
	Overload capacity	16kW, 10S
	Rated output Current	11.6A
	Max output Current	17.4A
	Communication	WIFI

PV side	Config.	20pcs* 600wp
	Input Power W	12000
	Input DC current	13.58A + 13.58A (2 channels)
	Input DC voltage	441.9V & 441.9V (2 channels)
	MPPT	2

Battery side	Type	LFP
	Voltage	51.2V
	Capacity	14.336kWh
	Charging current	140A
	Discharging current	140A
	BMS	Included
	Communication between BMS & PCS	RS485

Grid / Generators	Input voltage	AC, 3Phases,400/230V
	Input current	11.6A
	Max input current	17.4A
	Frequency	50Hz, 60Hz
	Power	No less than 8kW

EPS function		Yes
Protections		PV Input Lightning Protection, Anti-islanding Protection, PV String Input Reverse Polarity Protection, Insulation Resistor Detection, Residual Current Monitoring Unit, Output Over Current Protection, Output Shorted Protection
